• Biphasic technology.
• Universal AED algorithm for adult and paediatric patients.
• Energy delivered: 200 Joules for adult and 50 Joules for paediatric.
• Audible and visual prompts to guide users through complete operation sequence.
• Configurable CPR protocol.
• Lithium battery with more than 400 discharges of capacity.
• Configured according to ERC/AHA guidelines 2015 and its review of 2017.
• Automatic daily selftest ensures the device continual readiness.
• Portable and lightweight for easy transport in any situation.
• Rugged and durable design for any environment.
• Optional PC software, to store and review ECG data.

• Adult and paediatric disposable electrodes for defibrillation
• Carrying case (1)
• Ambulance bracket (EN1789:2007 certified) (2)
• Non rechargeable battery (3)
• “REANIBEX Data Manager” Software application to manage and organize all the data gathered (4)
• Wallcase with optional alarm system. Other models available with Communication systems (GSM, GPRS, CCTV camera…)


GENERAL

• Dimensions . 300mm(W) x 282mm(D) x 93mm(H) (including the handle)
• Weight . 2.75Kg (with the battery pack) . 2.2Kg (without battery pack)

DISPLAY

• Type . Graphic LCD with backlight
• Dimensions . 128 x 128 pixels (70 x 70mm)
• Speed . 25mm/second
• Sensivity . 1 cm/mV

AED DEFIBRILLATOR

• Waveform . Biphasic truncated exponential adjusted to the impedance of the patient
• Output energy . 200 Joules for adult patients and 50 Joules for pediatric patients
• Charging time . Less than 5 seconds at 200 Joules with a new fully charged battery at 25ºC
• Electrodes types . Disposable cable-electrodes for adults and for pediatrics with identifier
• Resuscitation guidelines . Factory set Guidelines 2018 (ERC/AHA) and its review of 2017

DATA STORAGE

• Internal memory capacity . 30 minutes of ECG recording
• Communications . PC connection (irDA)
• Data review . PC application (Reanibex Data Manager) for downloading, reproducing, handling, storing and reviewing recorded episodes (optional)

BATTERY

• Type . Non-rechargeable Lithium SO2 Battery Pack (12 VCD, 7,5 A/h)
• Capacity . Typical: 400 dicharges of 200 Joules or 12 hours of monitoring. Minium: 300 discharges of 200 Joules
• Shelf life . 5 years

ENVIRONMENT

• Operating temperature . From 0 to 50ºC
• Storage temperature . From -10 to 60ºC without the battery pack
• Relative humidity . From 10 to 95% (non-condensing)
• Shocks . EN 1789
• Vibrations . EN 1789
• Resistance to solids/water . IP44
